Energy in Physics: Potential and Kinetic Energy

Energy is typically defined as the capacity to perform work. In everyday terms, when individuals say they feel full of energy, it indicates that they have the ability to perform physical or mental activities.

In physics, energy exists in different forms. It can be classified into two main types: potential energy and kinetic energy. Both forms of energy are important in aviation, from the stored energy in aircraft fuel and springs to the energy of an aircraft moving along a runway.

Potential Energy

Potential energy is defined as stored energy associated with the position or condition of an object. Potential energy may be classified into three groups: (1) energy due to position, (2) energy due to the distortion of an elastic body, and (3) energy that can produce work through chemical action.

Examples of the first group include water in an elevated reservoir or an airplane raised off the ground with jacks. A stretched bungee cord on a Piper Tri-Pacer or a compressed spring are examples of the second group. Energy stored in aviation gasoline, food, or storage batteries represents the third group.

To calculate the potential energy of an object due to its position, such as its height above a reference level, the following formula is used:

Potential Energy = Weight × Height

A calculation based on this formula produces an answer in foot-pounds (ft-lb) or inch-pounds (in-lb), which are also units used for work. Work, which is covered later in this chapter, is described as a force applied over a measured distance, with the force expressed in pounds and the distance in feet or inches. Potential energy and work are therefore closely related.

Example: A Boeing 747 weighing 450,000 pounds needs to be raised 4 feet in the air so maintenance can be performed on the landing gear. How much potential energy does the airplane possess because of this raised position?

Potential Energy = Weight × Height
PE = 450,000 lb × 4 ft
PE = 1,800,000 ft-lb

As previously mentioned, aviation gasoline possesses potential energy because of its chemical composition. Gasoline has the potential to release heat energy, based on its British thermal unit (BTU) content.

One pound of aviation gasoline contains approximately 18,900 BTU of heat energy, and each BTU is equivalent to 778 ft-lb of work. Therefore, when we multiply 778 by 18,900, we find that one pound of aviation gasoline contains approximately 14,704,200 ft-lb of energy equivalent.

This represents the theoretical energy available from the fuel’s heat content. The actual useful mechanical work produced by an aircraft engine is lower because of energy losses and the engine’s thermal efficiency. Imagine the potential energy contained in the completely serviced fuel tanks of an airplane.

Kinetic Energy

Kinetic energy is defined as the energy an object possesses because of its motion. An airplane rolling down the runway or a rotating flywheel in an engine are both examples of objects possessing kinetic energy.

Kinetic energy has the same units as potential energy, namely foot-pounds or inch-pounds. To calculate the kinetic energy of an object in motion, the following formula is used:

Kinetic Energy = ½ × Mass × Velocity²

To use this formula in the English system of units, mass must be expressed in slugs and velocity in feet per second (ft/s). The mass of an object can be determined by dividing its weight in pounds-force by the acceleration due to gravity (approximately 32.2 ft/s² near the Earth’s surface). This produces kinetic energy in foot-pounds.

Example: An Airbus A380 weighing 600,000 lb is moving down the runway during its takeoff roll with a velocity of 200 ft/s. How many foot-pounds of kinetic energy does the airplane possess? [Figure 1]

Airbus A380 aircraft accelerating along the runway during takeoff, demonstrating kinetic energy in motion
Figure 1. Kinetic energy (Airbus A380 taking off)

Kinetic Energy = ½ × Mass × Velocity²
Kinetic Energy = ½ × (600,000 ÷ 32.2) × 200²
KE ≈ 372,670,000 ft-lb
